    DALI LED driver

    DALI Dimmable LED Driver 150W 24V

    99.90

    Out of stock

    SKU: LT-FTPC150V24DACategories: LED Accessories, LED Power Supplies, LED-drivers 24V

    Description

    POS DALI and PUSH dimmable LED driver. 150 Watts of power is enough for a little larger LED strip project as well. This LED driver is DALI (Digital Addressable Lighting Interface) and PUSH-dim adjustable.

    If you would like a remote controllable LED dimmer, you will not need this driver. In that case choose a normal LED driver where the dimming happens after the driver.

    This DALI/PUSH driver is suitable for example for 24 V DC LED strips, 24 V DC LED downlights, etc. Enough power for e.g. 12-13 meters of COB 12W LED strip. The size of this LED driver is L361.5 x W30 x H21.3 mm and that makes it a quite convenient sized LED driver. Regarding safety, this driver has a fault protection, overload protection and overheat protection. Out of these the fault and overload protection function with a power cut principle. It means that in a problem situation the LED driver will start to cut the power and makes the lights blink. Power cut continues until fault has been fixed. The overheat protection cuts the power from 24V side –> lights turn off. Lights can be turned on by turning the power back on. The protection works the same way in other high quality LED drivers as well. Cools itself with the surrounding ventilated air. In other words do not mount inside a small box.



    Compatible devices and controllers:

    DALI dimmers and other DALI system devices. DALI protocol IEC 62386.

    Benefits:

    • flicker-free dimming
    • Smooth adjustment
    • Slim design
    • Overload protection
    • Overheat protection
    • Fault protection
    • Full scale dimming 0.1% – 100%
    • 10% minimum load
    • Safe TUV-CE, RoHS

    Applications:

    • 24V LED strips
    • 24V LED downlights
    • 24V LED spotlights
    • 24V LED modules
    • 24V LED spots

    Specifications

    Kuormitus

    10% – 100%

    Käyttöjännite

    Himmennys

    0% – 100%

    Takuu

    24 months

    Maksimi teho

    150 W

    Lähtövirta

    6.25 A

    Lähtöjännite

    24V DC

    IP-luokitus

    IP20

    Käyttöympäristö

    ‘-20°C….+45°C

    Mitat

    361.5 x 30 x 21.3mm (L x W x H)

    Paino

    220 g

    Certificate

    CE

    Suojausluokka

    II

    Tehokerroin

    > 0.95

    Turvallisuus

    Fault protection, Overheat protection, Overload protection, Overvoltage protection
