RF receiver 1x8A
€29,90
Description
Single color RF receiver with 8A power. Suitable for single color dimmers. It is possible to pair max. 8 controllers for 1 receiver. All single color dimmers in this category are suitable such as HP1, HP2, HP3, mini button, 5-channel remote controller etc.
Dimmer and receivers sold separately.
Flicker-free dimming.
In addition to receiver you will need an LED-driver. If you have a 12 volt LED strip you will need a 12 volt LED-driver.
This can be controlled with a spring return lever button which is connected to the green screw connectors seen in the picture. On/off and dimming when button is held down. For example Schneider Exxact lever button is suitable. Electrical number 21 120 55.
Contents of the package:
1x8A receiver, 1 piece
English instruction manual, 1 piece
Specifications
| Operating voltage | |
|---|---|
| Max. power | 192W (24V), 96W (12V) |
| Size | 95x37x20mm |
| Weight | 100 g |
| Colour | White |
| RF frequency, distance | 434MHz ISM bandwidth, Over 20 meters in open area |
| Coupling | |
| Protection class | IP20 |
| Operating range | ‘-20°C…50°C |
| Installation | Installed between LED-driver and LED lights (for example LED strip) |
| Max. load | 1 x 8 A |
| Number of controllers | Max. 8 pieces |
| Certificate | CE, RoHS |
| Warranty | 2 years |
| Brand | Ledtek |
